EcoFlow Ecosystem & Accessories History

This document catalogs the “Eco-system” products that go beyond the basic power stations.

☀️ PowerStream (Balcony Solar System) (May 2023)

• Status: EOL (End of Life); replaced by the EcoFlow STREAM series.
• Type: Microinverter (Grid-Tied).
• Specs: 800W AC Output (Grid) / 800W PV Input.
• Battery Port: 600W DC Input/Output. Connects to almost ALL EcoFlow power stations (Delta/River) acting as a massive battery buffer.
• Unique Feature: Feeds solar to your home grid (Base load) and stores excess in the battery via a proprietary BKW-Battery cable.
• Successor: EcoFlow STREAM Microinverter & STREAM Ultra.

---

🌊 EcoFlow STREAM Series (Plug-and-Play Home Solar) (2024/2025)

The evolution of the balcony solar concept, moving to integrated stackable units and high-power microinverters. Managed via the EcoFlow OASIS AI platform.

STREAM Ultra (All-in-One System)

A stackable home battery system with an integrated grid-tied inverter.

• Models:

  • Ultra: 1.92 kWh (Base)

    ~23.1 kg.

  • Technical Note: Using Ultra during a Blackout.

  • Ultra X: 3.84 kWh (Large)

    ~38.8 kg.

• Solar Input: 2000W (4x MPPT @ 500W each

  16-60V).

• AC Output: 1200W (Grid-tied)

  2300W Bypass.

• Expansion: Stack up to 6 units (Max 11.52 kWh for Ultra / 23 kWh for Ultra X).
• Durability: IP65 / NEMA 4.
• Life Cycles: 6000 cycles to 70% capacity.

STREAM Microinverter

Next-gen standalone microinverter for use with existing rigid/flexible panels.

• PV Input: 1200W Max (3x MPPT

  16-60V).

• AC Output: 800W (Standard) / 600W (Software Limited).
• Cooling: Upgraded thermal sink design (No more overheating issues from V1).
• Durability: IP67 (Full outdoor immersion protection).

The OASIS AI Ecosystem

• Energy Optimization: Uses weather forecasting to predict solar yield and optimize battery usage.
• PowerInsight 2: The dedicated 10-inch touch console for the STREAM series. Supports Matter 1.4 for third-party smart home integration.

• Stacking Technology: Proprietary high-current pins on the top/bottom of Ultra modules (No external battery cables needed for stacking).

Comparison: PowerStream vs. STREAM Series

| Feature | PowerStream (V1) | STREAM Series (V2) | | :— | :— | :— | | System Type | Microinverter only | Integrated (Ultra) or Pro Micro | | Solar Max | 800W | 1200W (Micro) / 2000W (Ultra) | | MPPTs | 2 | 3 (Micro) / 4 (Ultra) | | IP Rating | IP67 | IP67 (Micro) / IP65 (Ultra) | | AI Control | Basic App | OASIS AI (Predictive) |

---

🚗 Alternator Charger (June 2024)

• Type: DC-DC Charger (Input from Car Alternator).
• Specs: 800W Charging Speed.
• Input: 11V-35V (Works with 12V/24V systems).
• Output: 40V-60V (Targeting Delta 2/Max/Pro battery voltage).
• Key Advantage: Charges a Delta 2 Max in ~2.5 hours while driving (vs 8+ hours on cig lighter).
• Tech: GaN (Gallium Nitride) for compactness.
• Reverse Charging: Can maintaining vehicle battery from the Power Station (Jump Start/Trickle).

🧊 Smart Devices (Glacier, Wave, Blade)

In 2023, EcoFlow expanded into “Smart Devices” that use their battery tech.

EcoFlow WAVE 3 (April 2025)

• Status: Current Flagship.
• Type: Portable Air Conditioner & Heater.
• Performance: 6100 BTU Cooling / 6800 BTU Heating.
• Battery: Uses add-on LFP battery (1024Wh) or connects to Delta 2/Max/Pro/3.
• Refrigerant: R290.
• Key Upgrade: Increased heating capacity and integration with Delta 3 series.

EcoFlow WAVE 2 (May 2023)

• Status: Legacy / Still Available.
• Type: Portable Air Conditioner & Heater.
• Performance: 5100 BTU Cooling / 6100 BTU Heating.
• Battery: Uses add-on battery (1159Wh) or connects to Delta 2/Max/Pro.
• Runtime: ~8 hours (Eco Mode).
• Refrigerant: R290 (Green).

EcoFlow GLACIER Classic (April 2025)

• Status: Current Model (Successor to original Glacier).
• Type: Portable Cooler/Freezer (Focus on space efficiency).
• Sizes: 35L, 45L, 55L options.
• Battery: Uses the same 298Wh plugin battery as the original Glacier.
• Key Differences: Removed Ice Maker to maximize storage volume (+30-40% space efficiency). Reversible door.

EcoFlow GLACIER (Original) (April 2023)

• Type: Portable Fridge/Freezer + Ice Maker.
• Key Feature: Integrated Ice Maker (18 cubes in 12 mins).
• Battery: 298Wh plug-in battery (optional).
• Cooling: Dual Zone (-25°C to 10°C).

EcoFlow BLADE (April 2023)

• Type: Robotic Lawnmower with Lawn Sweeping Kit.
• Key Tech: RTK GPS (No perimeter wire needed).
• Status: Officially Discontinued (Late 2023). Mixed reception due to complexity and navigation issues compared to competitors. EcoFlow has pivoted back to core energy storage products.

---

⚙️ Generators (Dual Fuel)

Smart generators designed to auto-start and charge the power stations efficiently.

Smart Generator 4000 (Dual Fuel) (2024)

• Output: 4000W Peak / 3200W Continuous.
• Fuel: Gasoline + LPG (Propane).
• Efficiency: 40% fuel savings vs traditional generators when paired with Delta Pro 3.
• Connectivity: App control, Auto-Start when Delta battery hits X%.

Smart Generator (Original Dual Fuel) (Dec 2022)

• Output: 1800W (Gas) / 1600W (LPG).
• Engine: 80cc 4-stroke.
• Integration: Seamless DC charging for Delta Pro/Max (Higher efficiency than AC charging).

---

🚐 Power Kits & Standalone LFP Batteries

The “Power Kit” system is modular, but some components (batteries) are useful standalone.

Standalone LFP Batteries (2kWh / 5kWh)

• SKU (2kWh): efm100-bpb
• SKU (5kWh): efm100-bpb-5k
• Chemistry: LiFePO4 (LFP) - 3000-3500 cycles.
• Voltage: 51.2V Nominal (16S).
• Capacity & Form Factor:

  • 2kWh: 40Ah

    ~17.1 kg (37.7 lbs)

    348 x 198 x 285 mm.

  • 5kWh: 100Ah

    ~40.6 kg (89.5 lbs)

    500 x 260 x 300 mm.

• Features: Built-in BMS, Auto-Heating (works down to -20°C).
• System Rules: You cannot mix 2kWh and 5kWh batteries in a single system. Max 3 batteries total (15kWh).

LFP Battery Polarity Adapter

• SKU: AB-CONV-PLUG
• Purpose: Adapts the proprietary EcoFlow battery port to standard terminals & CAN Bus for third-party systems.
• Communication (RJ45 CAN Port Pinout):
  • Pin 1: Wake / 12V Trigger
  • Pin 2: CAN High (H)
  • Pin 5: CAN Low (L)
  • Pin 6: Ground (GND)
• Note: Requires an RJ45 Terminator on the last battery in the chain for stable comms.

Left: Top view (Terminals) | Right: Bottom view (Battery Interface)

• Power Hub: The 5-in-1 brain (Inverter + DC-DC + MPPT) usually required if not using the Polarity Adapter.

Power Kit System Architecture (Mid-2022)

• Power Hub: Combines 2x MPPT, DC-DC Charger, Inverter, and DC-DC Converter.
  • Input: Solar (4800W), Alternator (1000W), Shore Power (3000W).
  • Output: 3600W AC (120V).
• AC/DC Distribution Panel: Manages 6 AC circuits and 12 DC circuits.
• Console: Central control panel for monitoring and settings.
• Smart Home Panel Integration: Can connect to the EcoFlow Smart Home Panel for whole-home backup.

---

⚡ XT60/XT60i Hack: LFP Battery to Portable Station

You can use a 2kWh/5kWh Power Kit Battery + Polarity Adapter (AB-CONV-PLUG) as a massive external battery for portable units like the Delta 2 or Delta Max.

The Setup:

LFP Battery -> Polarity Adapter -> XT60/XT60i Cable -> Portable Station (Solar Input)

The “3rd Pin” (XT60i) Logic:

EcoFlow uses the middle 3rd pin to detect the source.

• Pin Grounded/Detected: Unit identifies as Solar (Full power).
• Pin Open: Unit identifies as Car Charging (Limited to ~8A).

Main Unit	Cable Type	Speed	Result
Delta 2	XT60i (3rd pin on)	500W	Works perfectly as a high-speed DC buffer.
Delta Max 1600	Standard XT60 (2-pin)	200W	Stable charging.
Delta Max 1600	XT60i (3-pin)	FAIL	MPPT Cycle Loop: The station tries to draw too much, fails, and restarts the MPPT every few seconds.

Hack Tip: If you are using an XT60i cable with an older unit like the Delta Max 1600 and it kept rebooting, simply cover the middle pin with tape or use a simple 2-pin XT60 cable to force it into the stable 200W “Car Mode”.
